Product
Engaged in professional SMT processing，product category：PCB 、FPC、Rigid- Flex Board SMT processing，Our products are widely applied to digital camera，DVD burnes， Hd projectors，TV wall，sweeper，laser rangefinder，scanner，smart home，automotive electronics，and so on. At present also has the automobile tire pressure ，the automobile Panoramic all-in-line machine assembly production line。
Technology
The main SMT equipment model：NPM-W2，We can produce the PCB size：L50mm*W50mm到L750mm*W550mm；Elemental size：0603 chip~L150mm*W25mm*T30mm ，The minimum pitch of BGA ball：0.35mm。
Service
Professional SMT Production ability, as well as the Production Process Planning and External Communication allows us to provide customers with the most stable quality, the most competitive cost and the fastest shipping.
Specifications
| NO. | Variety | 基板Size (mm) |
基板殘邊Size(mm) | Component Dimension (mm) |
Print Accuracy | Placement Accuracy(Cpk≧1) | BGA、CSP （Ball/Pin pitch） |
| 1 | FPC | L50*W50~L350*W350 | >=5mm | 0603chip~L32*W32*T12 | ±25μm | ±50μm(chip),±50μm(QFP) | >=0.4mm |
| 2 | PCB | L50*W50~L750*W550 | >=5mm | 0603chip~L100*W90*T25 | ±25μm | ±50μm(chip),±30μm/QFP | >=0.35mm |
| 3 | Rigid- Flex Board |
L50*W50~L750*W550 | >=5mm | 0603chip~L100*W90*T25 | ±25μm | ±50μm(chip),±30μm/QFP | >=0.35mm |
